Chassis

• Suzuki's innovative and exclusive T-shaped seat provides maximum rider mobility during sport riding and while tackling difficult terrain.
• Overall length is under 82 inches so KingQuad 400ASi Camo 4 x 4 fits into a 6.5 foot truck bed.
• Independent front A-arm suspension design offers smooth performance and remarkable ground clearance and allows 6.7 inches of wheel travel.
• A swingarm rear-suspension system with 6.7 inches of wheel travel and class-exclusive twin shock absorbers provides agile handling and plush responsiveness.
• Dual front hydraulic disc brakes feature calipers with a large 34 mm piston diameter and maximum brake-pad surface area for increased stopping power and outstanding durability.
• Large, 25 inch Maxxis tires with aggressive dual-stage treaded pattern offers consistent traction in wet conditions and a quiet, smooth ride on hard-packed trails.
• Lightweight and strong plastic skid plates, sturdy enough to withstand pounding of trail hazards yet slippery to help let obstacles slide below.
• Suzuki's innovative and exclusive T-shaped seat provides maximum rider mobility during sport riding and while tackling difficult terrain.
• Overall length is under 82 in. so KingQuad 400ASi Camo 4x4 fits into a 6.5 ft. truck bed.
• Independent front A-arm suspension design offers smooth performance and remarkable ground clearance and allows 6.7 in. of wheel travel.
• A swingarm rear-suspension system with 6.7 in. of wheel travel and class-exclusive twin shock absorbers provides agile handling and plush responsiveness.
• Dual front hydraulic disc brakes feature calipers with a large 34 mm piston diameter and maximum brake-pad surface area for increased stopping power and outstanding durability.
• Large, 25 in. Maxxis tires with aggressive dual-stage treaded pattern offers consistent traction in wet conditions and a quiet, smooth ride on hard-packed trails.
• Lightweight and strong plastic skid plates, sturdy enough to withstand pounding of trail hazards yet slippery to help let obstacles slide below.

Engine

• The KingQuad 400ASi Camo features a fuel-injected 376 cc four-stroke, four-valve engine with new cam profiles and inner structures of the muffler (for more powerful and efficient performance).
• Suzuki's class-leading fuel injection contributes to smooth power output, especially, in the mid-to-high range, as well as more consistent cold starts. The fuel injection system uses 3-D ignition maps for optimum ignition, targeting a responsive yet environmentally efficient performance.
• Suzuki Advanced Cooling System (SACS) with factory-installed oil cooler and thermostat-controlled cooling fan helps cool engine during hard work or under excessive load.
• The KingQuad 400ASi Camo comes with electric start. A start-in-gear system - functional when the rear brake is applied - allows starting the engine without shifting to neutral when conditions warrant.
• The KingQuad 400ASi Camo features a fuel-injected 376 cc four-stroke, four-valve engine with new cam profiles and inner structures of the muffler (for more powerful and efficient performance).
• Suzuki's class-leading fuel injection contributes to smooth power output, especially, in the mid-to-high range, as well as more consistent cold starts. The fuel injection system uses 3-D ignition maps for optimum ignition, targeting a responsive yet environmentally efficient performance.
• Suzuki Advanced Cooling System (SACS) with factory-installed oil cooler and thermostat-controlled cooling fan helps cool engine during hard work or under excessive load.
• The KingQuad 400ASi Camo comes with electric start. A start-in-gear system—functional when the rear brake is applied—allows starting the engine without shifting to neutral when conditions warrant.

Special

• Minimum Age: 16 years old.
• Minimum Age: 16 years old.

Transmission

• Suzuki's technically advanced QuadMatic transmission-a fully automatic, CVT (Continuously Variable Transmission) with high-low range and reverse. Its advanced engine-braking system minimizes free-wheeling with the throttle off and helps control the vehicle during steep descents. (400ASi only)
• You can select two- or four-wheel drive operation with the flip of a handlebar-mounted lever. The KingQuad 400ASi Camo shaft drive system is reliable and durable, and provides nearly maintenance-free operation.
• A torque-sensing limited-slip front differential provides maximum traction and light steering effort when in 4WD mode.
• High-low selectable sub-transmission helps provide maximum versatility over a variety of terrain. An automotive gate-type gearshift lever lets you conveniently choose high- or low-range, neutral or reverse.
• Suzuki's technically advanced QuadMatic transmission—a fully automatic, CVT (Continuously Variable Transmission) with high-low range and reverse. Its advanced engine-braking system minimizes free-wheeling with the throttle off and helps control the vehicle during steep descents.
• You can select two- or four-wheel drive operation with the flip of a handlebar-mounted lever. The KingQuad 400ASi Camo shaft drive system is reliable and durable, and provides nearly maintenance-free operation.
• A torque-sensing limited-slip front differential provides maximum traction and light steering effort when in 4WD mode.
• High-low selectable sub-transmission helps provide maximum versatility over a variety of terrain. An automotive gate-type gearshift lever lets you conveniently choose high- or low-range, neutral or reverse.

Utility / Convenience

• Wrinkle paint finish on the racks and front bumper are durable and scratch resistance. Heavy-duty front and rear carrying racks let you easily take advantage of superb cargo-carrying capabilities.
• LCD digital instrumentation includes speedometer, odometer, tripmeter, hour meter, clock, fuel gauge and indicator lams for reverse gear, neutral, oil and FI.
• Automotive-style DC power outlet on front fender. A winch-ready chassis and factory-installed flexible tube routing for wiring make winch installation simple.
• Large 4.2 gallon fuel tank with fuel gauge for outstanding riding range.
• Full floorboards with integrated raised footpegs provide protection.
• Water-resistant underseat rear storage compartment.
• Wrinkle paint finish on the racks and front bumper are durable and scratch resistance. Heavy-duty front and rear carrying racks let you easily take advantage of superb cargo-carrying capabilities.
• LCD digital instrumentation includes speedometer, odometer, tripmeter, hour meter, clock, fuel gauge and indicator lams for reverse gear, neutral, oil and FI.
• Automotive-style DC power outlet on front fender. A winch-ready chassis and factory-installed flexible tube routing for wiring make winch installation simple.
• Large 4.2 gal. fuel tank with fuel gauge for outstanding riding range.
• Full floorboards with integrated raised footpegs provide protection.
• Water-resistant underseat rear storage compartment.
